rond 2.0 socket
removable module

Discover the rond 2.0 socket with its unique design. A huge step forward. For wider application possibilities. Now removable. Installation kit not included.



product overview

 29,00 (excl. VAT)

Product details

all-new module
endless possibilities

Installing in wood, veneer, stone, thin or thick plaster? With rond 2.0, the possibilities are endless. Choose the appropriate kit - multifit, retrofit or easyfit - for your specific application.

trimless or small trim
the choice is yours

Choose between a trimless cover ring (Ø48) and a small trim cover ring (Ø52), for easy plastering.

multifit
fits in wood, veneer and stone

The ultimate solution for furniture applications. With an outside diameter of only 52mm, multifit is the world’s sleekest removable socket. Requires a Ø48 hole and an 8-30mm panel thickness. Flush or with a small trim? The choice is yours.

+ removable
+ freely rotatable
+ wide range of finishes

retrofit
fits in universal Ø68 junction boxes

The ultimate solution for universal junction boxes, round or square. For both new build and renovations. Available trimless or with a small trim, for easy plastering. Electrical connections remain accessible after plastering. Removable by tool.

+ removable
+ every 45° rotatable
+ wide range of finishes

easyfit
fits in solid, plastered walls

The ultimate solution for brick walls. The Ø130 rond plaster box allows up to 3 times faster installation. Thanks to the all-new rond 2.0 module, electrical connections now remain accessible after plastering. Available trimless or with a small trim, for easy plastering. Same design, new possibilities.

+ removable
+ every 45° rotatable
+ wide range of finishes

the finishing touch
choose your finish

Choosing the application is one thing. Choosing the finish, however, rounds it off. We start with plastic: choose your black or white to aluminium all the way to brass ... The choise is yours.

A plastic finish (black or white) already results in a pleasing appearance. Aluminium is then an optimal base material. Black anodization and white structure powder coating are the standard finishes. Or choose your customized colour for a specific project. Looking for exclusive finishes on brass? The difference between aluminium and brass lies mainly in the options for finishes and the more rustic look and feel. Choose one of the five exclusive finishes: brushed nickel, light bronze, dark bronze, canon de fusil and blackened brass.

removable by tool
always accessible

The all-new rond socket can be removed from its kit after installation. In this way, wires remain accessible at any time.

Product details

icoon gewicht 0.2

Specifications

application
250V / 16A
flush-mounting depth
40 mm
wire stripping length
13,8 mm
wire capacity
up to 4 x 2.5 mm2 per terminal
wire fixation
screw terminals (TX8)
ambient temperature
-5 till +40°C
IP rating
IP21-D
IK rating
IK06
marking
CE
Other
patent pending
